page 25
The AFG has two footswitch input pins on the 15-way D
connector. This allows the footswitch to be assigned to
replicate one of each of the six main key functions,ON/OFF
MAX, UNITS, TXD, ZERO and RESET.
This feature is useful when integrating the AFG into test or
production systems.
Note: A footswitch assigned to the UNITS key can allow
entry into the menu, but the gauge will not respond to further
footswitch operations from either footswitch 1 or 2 once in the
menu.
To assign the function of a key to FOOTSWITCH 1 use UP
and DOWN keys to move the arrow key to FOOTSWITCH
1. Press ENTER key to access.
Using UP and DOWN keys select the relevant key (OFF,
MAX, UNITS, TXD, ZERO or RESET) and press the ENTER
key.
Press ESC key to return to page 2 of the main-menu.
To assign the function of a key to FOOTSWITCH 2 use UP
and DOWN keys to move the arrow key to FOOTSWITCH
2.
Using UP and DOWN keys select the relevant key (MAX,
UNITS, TXD, ZERO or RESET) and press the ENTER key.
Press ESC keys to return to page 2 of the main-menu.
Note: Footswitch 2 is multiplexed with the Smart Sensor
analogue voltage out. If a ‘Smart’ Sensor is attached,
Footswitch 2 functions are disabled.
Communications settings are selected to configure interfacing
of the AFG with peripheral devices. Also used to configure
the AFG to store up to a maximum of 100 readings in the
internal memory.
To set communications first use UP and DOWN keys to move
the cursor arrow to COMMS on page 2 of the main-menu.
Using UP and DOWN keys select the relevant option (see
below) and press the ENTER key.
FOOTSWITCH 1
Footswitch 1 sub-menu 1
FOOTSWITCH 2
Footswitch 2 sub-menu 1
COMMS
COMMS sub-menu 1
