page 27
Transmission of the displayed load reading can now be set to
include NULL (nothing), CR, LF or CR LF.
Use the UP or DOWN key to position the arrow cursor at the
desired setting.
Press ENTER to select.
A LINE DELAY, if any, to be executed after each reading is
sent, can now be set.
Use the UP or DOWN key to set this value from 0 to 5
seconds in one second intervals.
Press ENTER key to select.
For use with continuous readings only, a % threshold for the
start of transmission can now be set.
Use the UP or DOWN key to set this value from 1% to
100%.
Press ENTER key to select.
Method of transmission, RS232, MITUTOYO or BOTH, can
now be set.
Use the UP or DOWN key to position the arrow cursor at the
desired setting.
Press ENTER to select.
Now return to COMMS sub-menu 1
To set STORE MEM press ENTER key from
Comms sub-menu
1.
This will cause a memory counter to appear in the main
display. You will now return to COMMS sub-menu 1.
Note: The CYCLE counter and memory counters cannot
appear on the main display simultaneously. The last selected
is the one which will appear.
To set SEND MEM press ENTER key from
Comms sub-menu
1.
This will cause a TX symbol to flash in the main display as
the memory data is now transmitted to a peripheral device.
The data is transmitted at the settings defined by PORT. After
transmission of data you will now return to COMMS sub-
menu 1.
To set CLEAR MEM press ENTER key from
Comms sub-menu
1.
This now erases all the data stored in the memory. The
memory counter is now reset to zero. After clearing the
memory you will now return to COMMS sub-menu 1.
Press ESC key to return to page 2 of the main-menu.
Port sub-menu 4
Port sub-menu 5
Port sub-menu 6
Port sub-menu 7
