page 28
A constant multiplier of from 0.001 to 10.000 can be set for
a selectable base unit. Units will be replaced with an X on
the main display, and the UNITS key will have no effect on
the displayed units.
To set X CONSTANT, first use UP and DOWN keys to move
the cursor arrow to X CONSTANT on page 2 of the main-
menu and press the ENTER key.
The display will show X CONSTANT OFF and SET.
Press ENTER key to change X CONSTANT OFF to X
CONSTANT ON.
Press the DOWN key to move the arrow cursor to SET and
press ENTER key.
Using the UP and DOWN keys set the X CONSTANT
multiplier to the desired value. The unit this will apply to is
shown in the lower right corner of the screen and can be
adjusted with the UNITS key.
Press ESC key to return to page 2 of the main-menu.
Displays calibration information.
T - Tension span
C - Compression span
I - Initial Zero
G - Gravitational constant
Z - Current zero
This is for information only and may be required for
diagnostic purposes by your distributor.
Calibration menu - displays a password menu and allows the
user to check for load cell offset if overload is suspected.
Place the gauge (or your external SMART sensor) horizontally
on a flat level surface. By using UP or DOWN keys Select
the CAL option and the display will show 0000. Press the
ENTER key four times (to enter 0000 as the password), a
screen showing the % difference between the critical zero
and current reading will appear.(See Fig 12 overleaf). This
can be used as an indication of overload and the current
condition of the loadcell.
x/CONSTANT
X Constant sub-menu 1
INFORMATION
CALIBRATION
