Specifications
230V AC 50Hz or 110V AC 60Hz
DISPLACEMENT
Crosshead travel*** 1200mm (47.3”) 1000mm (39.4”) 500mm (19.7”)
Maximum headroom*** 1230mm (48.4”) 1030mm (40.6”) 530mm (20.9”)
STANDARD LOAD MEASUREMENT OPTIONS
Force gauge and dovetail bracket
S-beam loadcell, tension block module and AFTI display
MultiTest-d 0.5 1 2.5
TEST FRAME
R
ated capacity N 500 1000 2500
k
gf 50 100 250
lbf 110 220 550
N
umber of ballscrews 111
Speed range mm/min 1 - 1000 1 - 1000 1 - 1000*
in/min 0.04 - 40 0.04 - 40 0.04 - 40
Crosshead speed accuracy
Throat Depth** 70.5mm (2.8”) 70.5mm (2.8”) 70.5mm (2.8”)
Vertical daylight 1359mm (53.5”) 1159mm (45.6”) 590mm (23.2”)
Height 1710mm (67.3”) 1510mm (59.4”) 941mm (37”)
Width 290mm (11.4”) 290mm (11.4”) 290mm (11.4”)
Weight 38kg (84lbs) 36kg (79lbs) 22kg (49lbs)
Maximum Power Requirements 120 watts 200 watts 250 watts
Voltage
±0.1% of indicated speed
* 2.5kN - recommended maximum speed = 750mm/min (30in/min) above 2000N
** measured to centre line of the force gauge
*** measured with a force gauge and short extension rod fitted
