Insert the batteries with
positive (+) poles facing
out and slide on the
battery pack cover.
Your SONNET is
now turned on.
3
Connect the coil cable
to the DL-Coil.
4
The DL-Coil cover
is also available in a
locking version for
additional security.
Be careful not to use too much
force when you turn the battery
pack cover lock.
Note the orientation of
the plug. The logo and
arrow should face up.
Locked
Unlocked
Battery Pack Cover
Lock
3
