MED-EL Sonnet - SONNET Basic Assembly; Attaching Battery Pack and Coil Cable

Click!
Basic Assembly
Attach the battery
pack frame to the
control unit.
1
Plug the coil cable
into the control unit.
2
SONNET
Note the correct
orientation of the coil
cable socket.
Note the mechanism
that secures the control
unit to the frame.
To remove,
press the tip of
the release lever.
2
