Medalist Spectrum E-Tec - Page 7

5
1) LCD Monitor
3) Select / Change Button-Red 4) Yellow Player Button 2) Target
5) Coin Door Bill Validator (Optional)
6) Mail Slot 7) Side Door
8) Fan-Air Out 9) Hand Cup
14) AC Input 13) Soft Shutdown Switch
10) Back Door 11) GND Terminal
12) Speaker 15) Fan-Air In (Fan with Filter)
Front Side Back
Figure 1.2: Cabinet Configuration (M)
BY MEDALIST
