Medalist Spectrum E-Tec - 3 Cabinet Configuration

3 - Cabinet Configuration
4
Front Side Back
1) LCD Monitor
2) Target
3) Select/Change Button-Red
4) Player Button-Yellow
5) Coin Door Bill Validator (Optional)
6) Mail Slot 7) Side Door
8) Fan-Air Out 9) Hand Cup
14) AC Input 13) Soft Shutdown Switch
11) GND Terminal 10) Back Door
12) Speaker 15) Fan-Air In (Fan With Filter)
Figure 1.1: Cabinet Configuration (T)
