5EN
Assembly Instructions
lV
1
Snap membrane onto valve until
membrane lies completely flat.
b
+
c
2
Push assembled valve and memb-
rane onto breastshield. Ensure side-
wise position of valve as indicated on
picture.
+
b c
3
Screw bottle into breastshield.
a
+
db c
4
Slip rubber seal onto piston until it
snaps into place – the larger side faces
the handle. To ensure proper seal, hold
rubber seal firmly and twist piston.
+
i
h
a1
+
a2
