332
7.2. Back
0 –
1414 15 16 17 18 19 20 21
14) Bass reflex port
15) ~AC IN – Connection port for mains cable
16) 0/1– Mains switch
17) – Headphone connection, 3.5 mm stereo jack
18) LINE IN L/R – Connection port for external device (cinch connection)
19) AUX – Connection port for external device (jack connection)
20) USB – Connection port for USB storage medium
21) Connection for DAB/FM wire aerial
