TREADMILLS MOD. 870A/870S/870C
© Medisoft RAM Italia S.r.l.. All rights reserved.
33
7 Treadmill model 870 A technical specifications
Dimensions:
205 cm - length
80 cm - width
112 cm - height
(*)
(*)
with treadmill at zero inclination
Running surface:
50 X 150 cm
Distance of the running surface from the floor:
17 cm.
Working distance of the handrails from the
running surface:
93 cm
Weight:
163 kg
Patient capacity:
200 kg
Speed range:
0 – 20 km/h
Speed increments:
0.1 km/h (from 1,0 km/h min. speed)
Incline range:
0 – 25 %
Incline increments:
0.5 %
Speed motor:
Asynchronous three phase 2.0HP, AC (nominal power)
Elevation motor:
90 watt DC (nominal power)
Running belt:
Impact absorbing, self lubricating system
Thickness 2,7 mm.
Colours:
Surfaces: embossed metallic grey
Handrails: black
Belt: black
Safety devices:
• N. 2 (two) red stop switches
• Opt.005: safety lanyard (optional)
• Opt.004: paediatric handrails (optional)
Classification
1) Protection against electrical hazard:
• Class I
2) Protection against direct or indirect contacts:
• Type B applied part
3) Protection against water penetration:
• Common device IPXO
4) Safety level against air and oxygen flammable:
• Not protected
5) Utilization
• Continuous operation
Warnings:
The connection to the mains is indicated by a
light.
Data Input/Output:
Serial port: RS232 asynchronous
Connector: DB9 F
Baud rate: 4800 bps
Operation: Remote device interface
The treadmill 870 A must be connected to devices
meeting the EN 60950 standard only.
Not separable, 2P+T, 3x2,5 mm
2
,
length 3,0 m
Not separable, 2P+T, 3x4 mm
2
,
length 1.30 m
Utilisation conditions
Temperature: From 10 to 40 C°
Humidity: Lower than 85%
Storage and transport conditions
Temperature: From -10 to 60 C°
Humidity: Lower than 90%
Packaging: Carton box bound with wooden pallet
