● Rotate the M/CW/PW knob to manually rotate all images along x, y or z axis.
● Tap View > 0º/90º/180º/270º to rotate all images in a preset angle.
● Tap 3D/4D > 3D to rotate the 3D image by using the trackball.
To zoom out/in all images
Press the Zoom key on the control panel to zoom in or zoom out the image by rotating the
Depth knob. Meanwhile, a size multiplier is displayed in the information area of the basic
screen.
To inverse images
Tap 3D/4D > Inversion to inverse the gray values of anechoic structures on 3D image.
9
�
2
�
7 Optimizing 3D Image
To choose the color
●
Tap 3D/4D, tap the left/right part of 3D Chroma to choose the color scheme for the
3D image.
●
Tap 3D/4D, tap the left/right part of B Chroma to choose the color scheme for
reference images.
● Tap M-Slice, tap the left/right part of B Chroma to choose the color scheme for slices
The grayscale or color map on the top right of the imaging area varies with this
setting.
To set the contrast and transparency
● Tap 3D/4D, tap the left/right part of Contrast to set the contrast of the 3D image.
●
Tap 3D/4D, tap the left/right part of Transparency to set the transparency of the 3D
image.
To set threshold, smoothness and brightness
●
Tap 3D/4D, tap the Left/Right part of Threshold to set the threshold value of the 3D
image.
●
Tap 3D/4D, tap the Left/Right part of Smoothness to set the smoothness of the 3D
image.
●
Tap 3D/4D, tap the Left/Right part of Brightness to set the brightness of the 3D
image.
To adjust the light position
●
In S-Live mode, tap Edit Light on the touch screen, locate the light position using the
trackball, then press the confirm button on the control panel.
