Medivators DSD EDGE - Check Valve Replacement; Replacement Procedure


27 
A
NNUAL PM INSTRUCTIONS
PREVENTATIVE MAINTENANCE KIT
Check Valve Replacement
Each DSD EDGE endoscope reprocessor has three check valves located in both the A and B main manifold and two in
the B station water and disinfectant valves.
Parts Required Part number Qty
Check valves 78401-260 1 (Kit of 8 Check Valves &
16 Sealing O-rings)
Tools
 3/16-inch Allen wrench
 Silicone Grease
Procedure
 With the main module lying on a table, remove the four check valve block retaining screws with a 3/16-in Allen
wrench. Refer to figure 35.
 Once all four retaining screws are removed, gently rock the check valve block back and forth gently to release the
block with the check valves from the main manifold.
 With the block removed, note the orientation of the check valves. It is imperative the new check valves be reinserted
in the same direction. Refer to figure 36.
 Remove the check valve from the check valve block. Remove the O-ring from both ends of the check valve. The O-
ring may be found in both the check valve holes on both the check valve block and the main manifold.
