8. Troubleshooting
Problem Action
Air compressor will not If the green light in the mains switch is on, yet the motor does not
operate when switched on.
function, there is an internal fault. The machine should be returned
to the point of purchase or an authorised person for examination.
     Ifthegreenlight(s)ontheswitchesareo:
1. Check mains lead is securely connected each end.
2. For machines with a 3 pin plug (UK) remove and check the fuse
in the plug. Fuse - 3.15AL 25mm long.
3. Check mains fuse in the control panel. Fuse - T1AL 20mm long.
4. Disconnect unit from electricity supply. Check mains fuse in
the mains inlet socket.
Nebuliserchamberbubbles 1.Checkinletlter.Replaceifnecessary.
or produces little or no mist.
2. Wash nebuliser chamber. Replace if problem still occurs.
Time taken to nebulise
3. Check driveline tubing is not kinked or leaking. Replace if
signicantlyincreases.  necessary.
4. Service compressor.
9. Technical Specications
AC2000 Econoneb Turboneb 2
Country UK/EU UK/EU UK/EU
Operating Voltage 220V-240V / 50Hz 220V-240V / 50Hz 230V / 50Hz
Power Consumption 62VA (260mA) 64VA (270mA) 68VA (296mA)
Fuse 1 x T1AL 20mm long 1 x T1AL 20mm long 1 x T1AL 20mm long
Normal Flow
 minow7L/min,max minow7L/min,max minow9.5L/min,max
    ow9L/min@138kPa* ow9L/min@138kPa* ow10.5L/min@138kPa*
Weight 2.8kg (w/o starter pack) 2.7kg 2.7kg
Dimensions 375 x 235 x 115mm 210 x 185 x 185mm 210 x 185 x 185mm
Type Rating Class II BF Continuous Class II BF Continuous Class II BF Continuous
Sound Pressure Level 60 dbA approx. 63 dbA approx. 63 dbA approx.
*1kPa=0.01baror0.145psi
