12
Replacement parts:
HCS701311 – Suction Regulator Assembly Kits – Includes Pressure Gauge, Knob and
Tubing Nipple/Adapter.
Fuse Holder Assembly
12. Specifications/classifications
Dimensions (L) 375 x (W) 175 x (H) 250 mm
(14.8 x 6.8 x 9.8 in)
Weight 5.5 kg (12.1 lb)
Maximum Vacuum 560 ± 3% mm Hg
Flow Range > 40 LPM
Sound Level < 58 dBA
Electrical Requirements HCS7000: AC 115 V~60Hz
Power Consumption HCS7000: 70 watts
Hydrophobic Filter pore size 0.45 microns
Collection Bottle Capacity 800 ml (cc)
Operating Temperature 32° ~ 104° F (0° ~ 40°C)
Operating Humidity 95% RH
Operating Atmospheric Pressure 10.2 ~15.4 psi (70 ~106 kpa)
Storage Temperature 14° ~ 158° F ( -10° ~ 70°C )
Storage Humidity 0 ~ 95%
Storage Atmospheric Pressure 7.3 ~15.4 psi (50 ~106 kpa)
Fuse Specification Miniature Glass Fuse 5x20mm, Fast
Blow (Quick Acting), F2A/250 V
Equipment Classifications With respect to protection from electric
shock Class I
13. Warranty
Two years limited warranty
The compressor portion of the VAC-ASSIST Suction Unit is warranted to be free
from defective workmanship and materials for a period of two years from date of
purchase.
