Table 5
Guidance and manufacturer’s declaration - electromagnetic immunity
The device is intended for use in the electromagnetic environment specified below. The customer or the user of the
device, should assure that it is used in such an environment.
Radiated RF
IEC61000-4-3
(Test
specifications
for ENCLOSURE
PORT
IMMUNITY to
RF wireless
communications
equipment)
Test
Frequency
(MHz)
Band a)
(MHz)
Service a) Modulation b) Modulation b)
(W)
Distance
(m)
IMMUNITY
TEST
LEVEL
(V/m)
385 380-390 TETRA
400
Pulse
modulation b)
18Hz
1.8 0.3 27
450 380-390 GMRS 460,
FRS 460
FM c) ± 5kHz
deviation 1kHz
sine
2 0.3 28
710 704-787 LTE Band
13,
17
Pulse
modulation b)
217Hz
0.2 0.3 9
745
780
810 800-960 GSM
800/900,
TETRA 800,
iDEN 820,
CDMA 850,
LTE Band 5
Pulse
modulation b)
18Hz
2 0.3 28
870
930
1720 1700-1990 GSM 1800;
CDMA 1900;
GSM 1900;
DECT;
LTE Band 1, 3,
4,25; UMTS
Pulse
modulation b)
217Hz
2 0.3 28
1845
1970
2450 2400-
2570
Bluetooth,
WLAN,
802.11
b/g/n, RFID
2450, LTE
Band 7
Pulse
modulation b)
217 Hz
2 0.3 28
5240 5100-
5800
WLAN
802.11
a/n
Pulse
modulation b)
217 Hz
0.2 0.3 9
5240
5785
NOTE If necessary to achieve the IMMUNITY TEST LEVEL, the distance between the transmitting antenna and the
ME EQUIPMENT or ME SYSTEM may be reduced to 1 m. The 1 m test distance is permitted by IEC 61000-4-3.
a) For some services, only the uplink frequencies are included.
b) The carrier shall be modulated using a 50% duty cycle square wave signal.
c) As an alternative to FM modulation, 50% pulse modulation at 18 Hz may be used because while it does not
represent actual modulation, it would be worst case.
The MANUFACTURER should consider reducing the minimum separation distance, based on RISK MANAGEMENT,
and using higher IMMUNITY TEST LEVELS that are appropriate for the reduced minimum separation distance.
Minimum separation distances for higher IMMUNITY TEST LEVELS shall be
calculated using the following equation:
E=
Where P is the maximum power in W, d is the minimum separation distance in m, and E is the IMMUNITY
TEST LEVEL in V/m.
