DC 00573 TSA 2 Quick Set Up and Installation Overview Rev.1 Date of issue: 10.06. 2019 Page 5 of 9
Additional information can be found in the TSA 2 Operation Manual sections 6-10
Figure 8: Software Overview
System maintenance - Filling the Cooling unit
1. Use the kit AS 00171 to fill the cooling unit.
connect the syringe to the transparent tube without the connector, fill the syringe with coolant liquid
Use only coolant liquid from type Dowthern SR1 (or other coolant liquid approved by Medoc)
Figure 9: Filling the syringe with coolant liquid
1
2
3
Main Bar
Main
Toolbar
Status bar
