43
15. Clamp
16. Guide for starter cord
17. Starter handle
FIG. 1
ASSEMBLY
WARNING!
Always remove the cap from the spark plug,
switch o the lawn mower and wait until
all moving parts have completely stopped
before carrying out any maintenance and/or
cleaning.
PARTS
A. Spark plug spanner
B. Wing nuts with screw M8
C. Coach bolt M8 x 45
D. Screws M8 x 35
E. Clamp
F. Bottom handle
G. Deck with top handle
H. Grass catcher
FIG. 2
HANDLE
1. Fit the bottom handle on the lawn mower
with 1 screw (D) and 1 wing nut (B) on
each side.
FIG. 3
2. Fold out the top handle and lock in place
by tightening the wing nuts (B) and screws
(C). Check that the guide for the starter
cord is on the right side of the handle,
seen from behind the lawn mower.
FIG. 4
3. Fasten the cord to the engine lever in the
clamp.
4. Pull the starter handle towards the top
handle.
TECHNICAL DATA
Displacement 129,2 cm³
Output 1.9 kW
Engine speed 2900 min-¹
Catcher 45 l
Mowing width 41 cm
Mowing height 25-75 mm
Ignition TCI
Fuel tank 0.9 l
Fuel Unleaded petrol
Oil volume 0.4 l
Engine oil SAE30
Spark plug type LD K7TC
Net weight 21 kg
Sound pressure level, LpA
82 dB(A), K= 3 dB
Measured sound power level, LwA
95 dB(A), K= 3 dB
Guaranteed sound power level, LwA
96 dB(A), K= 3 dB
Vibration level
5.1 m/s², K= 1.5 m/s²
Always wear ear protection.
DESCRIPTION
1. Top handle
2. Engine control lever
3. Wing nut
4. Bottom handle
5. Ejector opening
6. Fuel cap
7. Spark plug cap
8. Air lter cover
9. Front wheel
10. Oil ller plug
11. Chassis
12. Lever to adjust mowing height
13. Back wheel
14. Grass catcher
