MEGAFLO DD - Page 8

8

NOTE
Coil heating performance based on a primary flow rate of 15L/min at 80°C.
Temperature rise is from 15°C to 60°C.
B
375
E
D
C
29
Ø 579
TEMPERATURE/PRESSURE
RELIEF VALVE
30°
45°
74
Figure 2 - Megaflo eco Direct
A
393
B
C
29
D
Ø 579
F
TEMPERATURE/PRESSURE
RELIEF VALVE
27°
47°
30°
45°
74
Figure 3 - Megaflo eco Indirect

