Megger S1-1068 User Manual

10. Battery indicator
The battery symbol on the LCD display contains four pairs of segments. The battery is monitored continuously when
the instrument is turned on. The charge remaining in the battery is indicated by segment pairs as follows:
Fully charged battery
50% charged battery
Tests cannot be started, insufficient charge
Symbol flashes when there is not enough charge
for a test and the instrument will turn itself off.
When mains power is present the indicator shows the battery is being charged by animating the segments of the bar
graph.
A blinking full battery icon indicates that the battery is prevented from charging due to the temperature being out of
the allowable charge temperature range, 0 ºC to 40 ºC, or that the battery has failed.
www.megger.com S1-568 / S1-1068 / S1-1568
21
Battery indicator

Megger S1-1068 Specifications

General

Category	Test Equipment
Model	S1-1068
Manufacturer	Megger
Type	Insulation Resistance Tester
Output Voltage	50 V, 100 V, 250 V, 500 V, 1000 V
Insulation Resistance Range	10 kΩ to 35 TΩ
Display	LCD with backlight
Interface	USB
Safety Rating	CAT IV 600 V
Safety Standards	IEC 61010-1
Test Modes	DAR, PI, DD, Ramp Test
Data Storage	1000 measurements
Power Supply	Rechargeable battery
Battery Type	Li-ion
