3. General Description
Megger’s new utility focused S1 range of Insulation Resistance Testers (IRT) consists of three models; one 5 kV, one 10
kV and one 15 kV. Resistance measurement capability is up to 15 TΩ for the 5 kV model, 35TΩ for the 10 kV and 50
TΩ for the 15 kV.
3.1 Features
S1-568 measures to 15TΩ and S1-1068, S1-1568 to 35 TΩ
8 mA noise rejection plus 4 filter options ensure highest quality resistance measurements
All models support diagnostic and over voltage tests - PI, DAR, DD, SV and ramp test
Remote Control (RC) mode via USB cable
Bluetooth® link for live streaming data to PC and downloading saved results
Rapid charge Li-ion battery pack
Operate and charge battery from AC source (except during test)
Safety rating : CAT IV 600 V (S1-568, S1-1068),
CAT IV 1000 V (S1-1568 only)
Advanced memory with time/date stamp
DC and AC voltmeter (30 V to 660 V)
Large display with backlight
Download of saved results to PowerDB Lite– USB or Bluetooth®.
www.megger.com
S1-568 / S1-1068 / S1-1568
6
General Description
