Megger S1-568 User Manual

15.2 Environmental Conditions
Altitude: 3000 m (5 kV, 10 kV)
4000 m (15 kV)
Operating temp.: -20 °C to 50 °C
Storage temp.: -25 °C to 65 °C
Humidity: 90% RH non-condensing at 40 °C
Ingress protection: IP65 (lid closed), IP40 (lid open)
15.3 General Specifications
Safety: Meets requirements of IEC 61010-1,
CATIV 600 V to 3000 m (5 kV, 10 kV)
Meets requirements of IEC 61010-1,
CATIV 1000 V to 4000 m (15 kV)
EMC: Meets the requirements of IEC61326-1
Dimensions:
5 kV, 10 kV L 315 mm x W 285 mm x H 181 mm
15 kV L 360 mm x W 305 mm x H 194 mm
Weight: 4.5 kg (5 kV, 10 kV)
6.5 kg (15 kV)
www.megger.com S1-568 / S1-1068 / S1-1568
35
