Megmeet Dex CM3000 User Manual

42 Annex IV Structural Detail Drawing
Full-Digital Control CO
2
/MAG/MIG Multi-FunctionWelding Machine
Annex IV Structural Detail Drawing
1 2 3 4 5 6 7 8
10
11 12
16
17
18
19
13 14
15
物料名称
9
1. Front Plastic Panel
2.Case
R29060817
R29140141
R11112688
3. Output Current
Plate
4. Output
Inductance
R22041541
5.Secondary Side
Radiator
R29110196
6. Output Diode
R26020216
7. HF Transformer
R23011796
8. M1 Main Power
Amplifier Board
R11112689
9. Main Radiating Fan
R34020061
10. Display Board
R11101270
(Dex CM3000）
R11101149
（
Dex PM3000 ）
11.Output Quick Plug
Positive Pole
30042791
12. Output Quick Plug
Negative Pole
30042790
13. Wire Feeding
Disc Shaft
R29130363
14. Wire Feeding
Accessory (with motor)
R29140271
（
Dex CM3000)
R29140181
（
Dex PM3000 ）
15. Current Hall Sensor
R27060045
16. Fan in the Machine
R34020064
17. M2 Main Control
Board
R11101148
18. Input Air Switch
R34010077
19. Input Cable
R13500126
订货号
物料编号
订货号
Attached Fig.4-1DexCM/PM3000Structural Detail Drawing
