51
1 – Scope of delivery
• Hammer drill
• Additional grip
• Crown-gear chuck
• Drill-chuck key
• Bit depth stop
• Tool box
• Operating Instructions
• Guarantee
2 – Technical information
Technical data
Current supply 230V~/50Hz
Rated power requirement 950 W
Idling speed 0–920 min
-1
No. of impacts 0–4850 min
-1
/
(no load) 2.0 J
Collar diameter ø 43 mm
Max drill diameter ø
- in metal 13 mm
- in concrete/stone/granite 26 mm
- in wood 30 mm
Power cord 300 cm
Technical changes reserved.
Noise emission/vibration
L
PA
: 89,0 dB(A), L
WA
: 102,0 dB(A).
Hand/arm vibrations a
w
: 7,8 m/s
2
.
3 – Components
1 Chuck
2 Grip
3 Depth stop
4 Selector switch for clockwise or
counterclockwise rotation
5 Speed-selector knob
6 ON/OFF switch
7 Lock button
8 Clamping collar
9 Selector switch Drill/Chisel
10 Additional handle
11 Crown-gear chuck
12 Drill-chuck key
13 Thumb screw
4 – Correct use
This hammer drill is suitable for drilling
in wood and metal, hammer-drilling in
Operating instructions & safety hints
WARNING! To reduce the risk of injury, please read the operating instruc-
tions through carefully before using the device, and then store with the
machine! When passing the device on to another user, these operating
instructions must also be included!
GB
Page
1 – Scope of delivery 51
2 – Technical information 51
3 – Components 51
4 – Correct use 51
5 – General safety
instructions 52
6 – Safety instructions
relating specifically to
the equipment 54
Page
7 – Installation and setting 54
8 – Operation 55
9 – Mode of operation 56
10 – Maintenance and
environmental
protection 57
11 – Service instructions 58
Contents
