56
2. – Tighten and loosen screws in
conjunction with a conventional
chuck (11) and suitable bits
and bit holders (not supplied).
Hammer drilling in concrete
and masonry without additional
chuck. To do this, suitable
hammer drills (14) are inserted
into the chuck (1).
Chiselling in tiles and masonry.
To this end, suitable chisels (13)
are inserted into the chuck (1).
The tool’s turning function is
switched off in this type of
operation.
Adjusting working angle. In this
position, a chisel clamped in the
chuck can be manually turned to
set a favourable working angle of
the chisel to the tool. As soon as
the selector switch is turned to the
chisel type of operation ( ), the
working angle set is locked and
retained during operation.
Starting and stopping
The voltage of the power supply must
comply with the voltage stated on the
machine plate.
Quick-action switch (Fig. 9)
• Switching on: Press ON/OFF switch (6)
• Switching off: Release ON/OFF
switch (6)
Continuous mode (Fig. 9)
• Switching on: Press ON/OFF switch (6)
and then press locking button (7).
• Switching off: Press ON/OFF switch (6)
and release.
Switching clockwise or counterclock-
wise rotation (Fig. 11)
• For hammer-drilling, drilling, inserting
screws: Set selector switch (4) to
position "clockwise rotation".
• For loosening screws: Set selector
switch (4) to position "Left rotation".
ATTENTION! Only switch over
when the motor comes to a
complete stop!
Information: The speed for
counterclock rotation is reduced
by the tool design. With increased
speed of counterclock rotation there
may be therefore more sparking in
the motor`s commutator. This is
normal and is not indicative of any
defects.
9 – Mode of operation
ATTENTION! All insertion tools
illustrated are not included in the
delivery!
ATTENTION! When working,
always hold the tool firmly with
both hands!
Chiselling in tiles and masonry
(Figs. 12/13/14)
Insert the chisel into the chuck (1) as
described above. When using a flat
chisel, turn the selector switch for the
type of operation (9) to the position
and turn the chisel to set a favourable
working angle. Lock the set chisel
setting by turning to the position ( ).
