15
NATURAL GAS CONVERSION
15. Open the side burner lids and
remove the griddle and grate. On the left
hand side, remove the R-pin at the back
of the main burner to detach it from
bracket and then take the burner out. On
the right hand side, remove the 3 screws
around each side burner with a Phillips
head screwdriver (CC), loosen the
ignition pin underneath, and then take
the side burners out.
Hardware Used
x 1
16. Adjust main burners’ air shutters as
shown by loosening the air shutter
screws with the Phillips head
screwdriver (CC).
Hardware Used
x 1
17. Adjust side burners’ air shutters as
shown by loosening the air shutter
screws with the Phillips head
screwdriver (CC).
Hardware Used
x 1
Phillips Head
Screwdriver
CC
Phillips Head
Screwdriver
CC
Phillips Head
Screwdriver
CC
R Pin
Griddle
Screws
Grate
15
16
17
