16
NATURAL GAS CONVERSION
18. Remove the LP orifices of the main
burners and the side burners with the
orifice removal tool (BB) and install the
Φ1.45mm orifice (GG).
Hardware Used
x 1
x 3
19. Re-install the side burners. Make
sure the orifices are aligned with the
burners and the ignition pins are
installed in their original positions. Check
for sparks before operating your grill.
20. Put the burners back in the firebox,
followed by the griddle and the grate.
Hardware Used
x 1
Ignition Pin
Orifice
Removal Tool
BB
GG
Φ1.45mm Orifice
Phillips Head
Screwdriver
CC
20
18
To Next Page
