CONNECTIONS (CONTINUED)
CONNECTING AN EXTERNAL AUDIO UNIT
From
Audio
Out
To
Audio In
EXTERNAL AUDIO SOURCE
KARAOKE UNIT
NOTES:
• Connecting the unit to an external audio source will allow you to broadcast the external unit’s sound through the
MKS8501’s speakers.
• When connecting the external unit, refer to the owner’s manual of the external unit, as well as this manual.
• When connecting the external unit, make sure the power is off and both units are unplugged before making any
connections.
CONNECTING AN EXTERNAL VIDEO UNIT
From
Video Out
To video
In
EXTERNAL VIDEO SOURCE
KARAOKE UNIT
NOTES:
• Connecting the unit to an external video source will allow you to see the external unit’s video through the
MKS8501’s monitor.
• When connecting the external unit, refer to the owner’s manual of the external unit, as well as this manual.
• When connecting the external unit, make sure the power is off and both units are unplugged before making any
connections.
Rotate the MONITOR switch to
the AUX position when
connecting the unit as per this
step.
Rotate the MONITOR switch to
the AUX position when
connecting the unit as per this
step.
