Memorex MT1132 Service Manual

Part No. Description Part No. Description
CAPACITORS CAPACITORS
C341 5345-104-50 0.1 uF +-20% 50V Electrolytic C673 5359-3321959 3300 pF +-10% 400V Polypropylene
C342 5345-104-50 0.1 uF +-20% 50V Electrolytic C674 5345-106-250 10 uF +-20% 250V Electrolytic
C343 5345-104-50 0.1 uF +-20% 50V Electrolytic C675 5345-108-25 1000 uF +-20% 25V Electrolytic
C344 V5361-S17BK101 100 pF +-10% 50V Ceramic B C676 5345-108-16 1000 uF +-20% 16V Electrolytic
C345 V5361-S17BK101 100 pF +-10% 50V Ceramic B C678 5345-107-25 100 uF +-20% 25V Electrolytic
C346 V5361-S17BK101 100 pF +-10% 50V Ceramic B C681 5354-104K1HM 0.1 uF +-10% 50V Mylar
C361 5354-102K1HM 1000 pF +-10% 50V Mylar C682 5345-228-06 2200 uF +-20% 6.3V Electrolytic
C362 V5361-S17BK101 1000 pF +-10% 50V Ceramic B C683 5359-1031959 0.01 uF +-10% 400V Polypropylene
C380 5345-105-50 1 uF +-20% 50V Electrolytic C701 5345-337-16 330 uF +-20% 16V Electrolytic
C381 V5369-S04FZ103 0.01 uF +80%-20% 25V Semiconductor C702 5345-476-16 47 uF +-20% 16V Electrolytic
C391 5345-105-50 1 uF +-20% 50V Electrolytic C703 5345-105-50 1 uF +-20% 50V Electrolytic
C501 5345-L225M50 2.2 uF +-20% 50V Electrolytic L.L C704 V5361-S17BK101 100 pF +-10% 50V Ceramic B
C503 5354-333K1HM 0.033 uF +-10% 50V Mylar C705 5345-476-16 47 uF +-20% 16V Electrolytic
C504 V5361-S17BK471 470 pF +-10% 50V Ceramic B C706 V5369-S05BK102 1000 pF +-10% 50V Semiconductor
C505 5354-104593 0.1 uF +-5% 50V TF C721 5361-S40EM472 4700 pF +-20% 250V Ceramic
C506 5345-107-25 100 uF +-20% 25V Electrolytic C722 5361-S40EM472 4700 pF +-20% 250V Ceramic
C507 5354-473K1HM 0.047 uF +-10% 50V Mylar C751 5345-474-50 0.47 uF +-20% 50V Electrolytic
C508 5345-108-25 1000 uF +-20% 25V Electrolytic C752 5345-108-16 1000 uF +-20% 16V Electrolytic
C509 5345-L225M50 2.2 uF +-20% 50V Electrolytic L.L C753 5354-104593 0.1 uF +-5% 50V TF
C510 5345-L335M50 3.3 uF +-20% 50V Electrolytic L.L C754 V5361-S17CK4R7 40 uF +-10% 50V Ceramic CH
C511 5345-107-25 100 uF +-20% 25V Electrolytic C801 5345-475-50 4.7 uF +-20% 50V Electrolytic
C512 V5361-S17BK101 100 pF +-10% 50V Ceramic B C802 V5369-S03XM222 2200 pF +-20% 16V Semiconductor
C551 V5369-S04FZ103 0.01 uF +80%-20% 25V Semiconductor C803 5345-476-16 47 uF +-20% 16V Electrolytic
C552 5345-225-50 2.2 uF +-20% 50V Electrolytic C804 5345-227-16 220 uF +-20% 16V Electrolytic
C553 V5369-S04FZ103 0.01 uF +80%-20% 25V Semiconductor C805 5369-104144 0.1 uF +-10% 25V Semiconductor
C554 5345-107-16 100 uF +-20% 16V Electrolytic C806 5345-108-25 1000 uF +-20% 25V Electrolytic
C555 5345-106-50 10 uF +-20% 50V Electrolytic
C556 5345-106-50 10 uF +-20% 50V Electrolytic RESISTORS
C557 5361-R01BK331 330 pF +-10% 500V Ceramic
C559 5352-S020J432 4300 pF +-5% 1.6 kV Metalized Polyester R3 V5133-R010J473 47 k ohm +-5% 1/8W Carbon
C560 5352-S321J394 0.39 uF +-5% Metalized Polyester R4 V5133-R010J473 47 k ohm +-5% 1/8W Carbon
C561 5361-S11BK331 330 pF +-10% 2 kV Ceramic R5 5135-150J50P 15 ohm +-5% 1/2W Carbon
C562 5345-105-50 1 uF +-20% 50V Electrolytic R6 5135-150J50P 15 ohm +-5% 1/2W Carbon
C601 5352-S331K104 0.1 uF+-10% Metalized Polyester R101 5134-472J25P 4.7 k ohm +-5% 1/4W Carbon
C602 5361-S40FM103 0.01 uF +-20% 250V Cetamic F R102 5134-472J25P 4.7 k ohm +-5% 1/4W Carbon
C604 5361-S40FM103 0.01 uF +-20% 250V Cetamic F R103 5134-101J25P 100 ohm +-5% 1/4W Carbon
C605 5361-S40FM103 0.01 uF +-20% 250V Cetamic F R104 5134-101J25P 100 ohm +-5% 1/4W Carbon
C606 5361-S09VZ103 0.01 uF +80%-20% 250V Ceramic R105 V5133-R010J102 1 k ohm +-5% 1/8W Carbon
C607 5345-S48LM227 220 uF +-20% 200V Electrolytic R106 V5133-R010J223 22 k ohm +-5% 1/8W Carbon
C608 5345-226-160 22 uF +-20% 160V Electrolytic R107 V5133-R010J223 22 k ohm +-5% 1/8W Carbon
C609 5345-336-160 33 uF +-20% 160V Electrolytic R110 V5133-R010J223 22 k ohm +-5% 1/8W Carbon
C611 5345-108-25 1000 uF +-20% 25V Electrolytic R112 V5133-R010J223 22 k ohm +-5% 1/8W Carbon
C614 5361-S40FM103 0.01 uF +-20% 250V Cetamic F R113 V5133-R010J103 10 k ohm +-5% 1/8W Carbon
C616 5345-S59MM105 1 uF +-20% 250V Electrolytic R114 V5133-R010J102 1 k ohm +-5% 1/8W Carbon
C664 5345-107-16 100 uF +-20% 16V Electrolytic R116 V5133-R010J102 1 k ohm +-5% 1/8W Carbon
C671 5359-3321959 3300 pF +-10% 400V Polypropylene R119 5134-102J25P 1 k ohm +-5% 1/4W Carbon
C672 5359-3321959 3300 pF +-10% 400V Polypropylene R120 5134-102J25P 1 k ohm +-5% 1/4W Carbon
Ref No. Ref No.
- 20 -
