Part No. Description Part No. Description
RESISTORS TRANSISTORS
R617 5275-S080K152 1.5 k ohm +-10% 5W Cement Q101 5613-C143ZS Transistor, DTC143ZS
R671 5102-S101J2R2 2.2 ohm +-5% 1/4W Fuse Q102 5613-2785(F) Transistor, 2SC2785(F)
R673 5102-S101J2R2 2.2 ohm +-5% 1/4W Fuse Q173 5613-2785(F) Transistor, 2SC2785(F)
R674 5171-S071J183 18 k ohm +-5% 1W Metal Q301 5613-2785(F) Transistor, 2SC2785(F)
R675 V5133-R010J105 1 M ohm +-5% 1/8W Carbon Q302 5611-1175(F) Transistor, 2SA1175(F)
R701 5135-221J50P 220 ohm +-5% 1/2W Carbon Q303 5613-2785(F) Transistor, 2SC2785(F)
R702 V5133-R010J752 7.5 k ohm +-5% 1/8W Carbon Q304 5611-1175(F) Transistor, 2SA1175(F)
R703 V5133-R010J750 75 ohm +-5% 1/8W Carbon Q351 5613-C143ZS Transistor, DTC143ZS
R704 V5133-R010J222 2.2 k ohm +-5% 1/8W Carbon Q551 5613-1473A(R) Transistor, 2SC1473A(R)
R705 V5133-R010J102 1 k ohm +-5% 1/8W Carbon Q552 5614-1877 Transistor, 2SD1877;(HORIZONTAL)
R707 V5133-R010J181 180 ohm +-5% 1/8W Carbon Q601 5613-2785(F) Transistor, 2SC2785(F)
R708 V5133-R010J153 15 k ohm +-5% 1/8W Carbon Q701 5613-2785(F) Transistor, 2SC2785(F)
R709 V5133-R010J154 150 k ohm +-5% 1/8W Carbon Q703 5613-2785(F) Transistor, 2SC2785(F)
R711 V5133-R010J221 220 ohm +-5% 1/8W Carbon Q751 5613-2785(F) Transistor, 2SC2785(F)
R712 5135-331J50P 330 ohm +-5% 1/2W Carbon Q752 5613-2785(F) Transistor, 2SC2785(F)
R721 5135-S051J335 3.3 M ohm +-5% 1/2W Carbon Q753 5613-2785(F) Transistor, 2SC2785(F)
R751 V5133-R010J153 15 k ohm +-5% 1/8W Carbon Q801 5613-2785(F) Transistor, 2SC2785(F)
R752 V5133-R010J102 1 k ohm +-5% 1/8W Carbon Q802 5613-2120(O) Transistor, 2SC2120(O)
R754 V5133-R010J101 100 ohm +-5% 1/8W Carbon Q803 5611-950(O) Transistor, 2SA950(O)
R755 V5133-R010J153 15 k ohm +-5% 1/8W Carbon
R756 V5133-R010J102 1 k ohm +-5% 1/8W Carbon INTEGRATED CIRCUITS
R757 V5133-R010J182 1.8 k ohm +-5% 1/8W Carbon
R758 V5133-R010J101 100 ohm +-5% 1/8W Carbon IC101 5654-TA87C-B2 IC;(u-COM)
R760 V5133-R010J102 1 k ohm +-5% 1/8W Carbon IC102 5654-S24C02BP IC;(EEPROM)
R761 5102-S101J2R2 2.2 ohm +-5% 1/4W Fuse IC301 5653-TA1268N IC, TA1268N ;(IF/VIDEO/CHROMA/DEF)
R801 V5133-R010J471 470 ohm +-5% 1/8W Carbon IC311 5653-NJ7809FA IC, NJM7809FA;(9V REGULATOR)
R802 V5133-R010J103 10 k ohm +-5% 1/8W Carbon IC501 5652-AN5512 IC, AN5512;(VERTICAL)
R803 V5133-R010J102 1 k ohm +-5% 1/8W Carbon IC601 5653-STR30130 IC, STR30130;(AVR)
R804 V5133-R010J103 10 k ohm +-5% 1/8W Carbon IC671 5653-NJ7805LD IC, NJM78LR05L-D;(5V REGULATOR/RESET 4.2V)
R805 V5133-R010J151 150 ohm +-5% 1/8W Carbon IC701 5624-TLP651 Photo-Interrupter;(VIDEO)
R806 V5133-R010J471 470 ohm +-5% 1/8W Carbon IC702 5624-TLP631 Photo-Interrupter;(AUDIO)
R807 5134-151J25P 150 ohm +-5% 1/4W Carbon
R809 5134-2R2J25P 2.2 ohm +-5% 1/4W Carbon
R810 V5133-R010J1R0 1 ohm +-5% 1/8W Carbon
R811 V5133-R010J2R2 2.2 ohm +-5% 1/8W Carbon
R812 5102-S111J100 10 ohm +-5% 1/2W Fuse
Ref No. Ref No.
- 22 -
