Memorex MT1132 Service Manual

Part No. Description Part No. Description
RESISTORS RESISTORS
R121 5134-562J25P 5.6 k ohm +-5% 1/4W Carbon R334 5135-124J50P 120 k ohm +-5% 1/2W Carbon
R122 5134-562J25P 5.6 k ohm +-5% 1/4W Carbon R335 5232-683J16P 68 k ohm +-5% 1/6W Carbon
R123 5134-562J25P 5.6 k ohm +-5% 1/4W Carbon R336 V5133-R010J222 2.2 k ohm +-5% 1/8W Carbon
R124 5134-562J25P 5.6 k ohm +-5% 1/4W Carbon R340 V5133-R010J105 1 M ohm +-5% 1/8W Carbon
R126 V5133-R010J223 22 k ohm +-5% 1/8W Carbon R341 V5133-R010J821 820 ohm +-5% 1/8W Carbon
R127 V5133-R010J274 270 k ohm +-5% 1/8W Carbon R342 V5133-R010J821 820 ohm +-5% 1/8W Carbon
R128 V5133-R010J222 2.2 k ohm +-5% 1/8W Carbon R343 V5133-R010J821 820 ohm +-5% 1/8W Carbon
R129 V5133-R010J103 10 k ohm +-5% 1/8W Carbon R344 V5133-R010J103 10 k ohm +-5% 1/8W Carbon
R131 V5133-R010J332 3.3 k ohm +-5% 1/8W Carbon R350 5134-471J25P 470 ohm +-5% 1/4W Carbon
R132 V5133-R010J332 3.3 k ohm +-5% 1/8W Carbon R351 V5133-R010J221 220 ohm +-5% 1/8W Carbon
R133 V5133-R010J562 5.6 k ohm +-5% 1/8W Carbon R361 5134-102J25P 1 k ohm +-5% 1/4W Carbon
R134 V5133-R010J123 12 k ohm +-5% 1/8W Carbon R362 5134-393J25P 39 k ohm +-5% 1/4W Carbon
R136 5232-104J16P 100 k ohm +-5% 1/6W Carbon R381 5135-821J50P 820 ohm +-5% 1/2W Carbon
R137 V5133-R010J153 15 k ohm +-5% 1/8W Carbon R391 V5133-R010J753 75 k ohm +-5% 1/8W Carbon
R142 V5133-R010J102 1 k ohm +-5% 1/8W Carbon R463 5102-3R35716 3.3 ohm +-5% 1W Fuse
R146 V5133-R010J102 1 k ohm +-5% 1/8W Carbon R501 5134-102J25P 1 k ohm +-5% 1/4W Carbon
R151 V5133-R010J102 1 k ohm +-5% 1/8W Carbon R503 5134-101J25P 100 ohm +-5% 1/4W Carbon
R152 V5133-R010J102 1 k ohm +-5% 1/8W Carbon R504 V5133-R010J153 15 k ohm +-5% 1/8W Carbon
R176 V5133-R010J103 10 k ohm +-5% 1/8W Carbon R505 5134-471J25P 470 ohm +-5% 1/4W Carbon
R177 V5133-R010J333 33 k ohm +-5% 1/8W Carbon R507 5134-563J25P 56 k ohm +-5% 1/4W Carbon
R178 V5133-R010J563 56 k ohm +-5% 1/8W Carbon R508 V5133-R010J333 33 k ohm +-5% 1/8W Carbon
R179 V5133-R010J183 18 k ohm +-5% 1/8W Carbon R509 5134-1R5J25P 1.5 ohm +-5% 1/4W Carbon
R180 V5133-R010J683 68 k ohm +-5% 1/8W Carbon R510 V5133-R010J562 5.6 k ohm +-5% 1/8W Carbon
R181 V5133-R010J333 33 k ohm +-5% 1/8W Carbon R518 5232-223J16P 22 k ohm +-5% 1/6W Carbon
R192 V5133-R010J102 1 k ohm +-5% 1/8W Carbon R519 5232-563J16P 56 k ohm +-5% 1/6W Carbon
R193 V5133-R010J102 1 k ohm +-5% 1/8W Carbon R551 5134-222J25P 2.2 k ohm +-5% 1/4W Carbon
R212 V5133-R010J103 10 k ohm +-5% 1/8W Carbon R554 V5133-R010J473 47 k ohm +-5% 1/8W Carbon
R213 V5133-R010J391 390 ohm +-5% 1/8W Carbon R555 V5133-R010J153 15 k ohm +-5% 1/8W Carbon
R214 V5133-R010J563 56 k ohm +-5% 1/8W Carbon R556 V5133-R010J562 5.6 k ohm +-5% 1/8W Carbon
R218 V5133-R010J102 1 k ohm +-5% 1/8W Carbon R557 V5133-R010J102 1 k ohm +-5% 1/8W Carbon
R220 V5133-R010J102 1 k ohm +-5% 1/8W Carbon R558 5134-331J25P 330 ohm +-5% 1/4W Carbon
R301 V5133-R010J182 1.8 k ohm +-5% 1/8W Carbon R559 V5133-R010J331 330 ohm +-5% 1/8W Carbon
R302 V5133-R010J182 1.8 k ohm +-5% 1/8W Carbon R560 5171-S071J332 3.3 k ohm +-5% 1W Metal
R303 5134-182J25P 1.8 k ohm +-5% 1/4W Carbon R561 5275-S080K332 3.3 k ohm +-10% 5W Cement
R305 V5133-R010J332 3.3 k ohm +-5% 1/8W Carbon R562 5135-0R5J50P 0.5 ohm +-5% 1/2W Carbon
R306 V5133-R010J331 330 ohm +-5% 1/8W Carbon R563 5173-S051J331 330 ohm +-5% 2W Metal
R307 V5133-R010J331 330 ohm +-5% 1/8W Carbon R570 V5133-R010J391 390 ohm +-5% 1/8W Carbon
R308 5134-182J25P 1.8 k ohm +-5% 1/4W Carbon R601 5179-S010K2R7 2.7 ohm +-10% 5W Cement
R309 V5133-R010J332 3.3 k ohm +-5% 1/8W Carbon R603 5276-S021J271 270 ohm +-5% 10W Cement
R310 V5133-R010J102 1 k ohm +-5% 1/8W Carbon R604 5134-123J25P 12 k ohm +-5% 1/4W Carbon
R319 V5133-R010J221 220 ohm +-5% 1/8W Carbon R605 5134-334J25P 330 k ohm +-5% 1/4W Carbon
R320 V5133-R010J221 220 ohm +-5% 1/8W Carbon R606 5102-S101J470 47 ohm +-5% 1/4W Fuse
R321 V5133-R010J221 220 ohm +-5% 1/8W Carbon R607 V5133-R010J472 4.7 k ohm +-5% 1/8W Carbon
R322 V5133-R010J332 3.3 k ohm +-5% 1/8W Carbon R610 5275-S080K152 1.5 k ohm +-10% 5W Cement
R328 V5133-R010J222 2.2 k ohm +-5% 1/8W Carbon R611 5135-681J50P 680 ohm +-5% 1/2W Carbon
R329 V5133-R010J562 5.6 k ohm +-5% 1/8W Carbon R612 5173-S051J332 3.3 k ohm +-5% 2W Metal
R330 V5133-R010J224 220 k ohm +-5% 1/8W Carbon R613 5173-S051J272 2.7 k ohm +-5% 2W Metal
R332 5134-102J25P 1 k ohm +-5% 1/4W Carbon R615 5134-180J25P 18 ohm +-5% 1/4W Carbon
R333 5135-124J50P 120 k ohm +-5% 1/2W Carbon R616 5173-S051J272 2.7 k ohm +-5% 2W Metal
- 21 -
