Memorex MT1132 Service Manual

Part No. Description Part No. Description
DIODES COILS AND TRANSFORMERS
D8 5635-HZT33 Zener, HZT33 33V 400 mW L101 5995-470098 Coil 47 uH
D9 5635-RD5R1EB2 Zener, RD5.1EB2 5.1V L203 5995-220098 Coil 22 uH
D301 5636-1N4148M Diode L301 5995-150098 Coil 15 uH
D302 5636-1N4148M Diode L361 5995-5R6098 Coil 5.6uH
D303 5636-1N4148M Diode L602 5583-52301 Coil AF CH;(LINE FILTER)
D306 5636-1N4148M Diode L701 5995-2R2098 Coil 2.2 uH
D308 5636-1N4148 Diode T202 5932-12502 Coil;(AFT)
D309 5636-1N4148M Diode T203 5562-0019 Transformer (SIF DET)
D310 5636-1N4148M Diode T552 5581-18801 Transformer
D311 5636-1N4148M Diode T671 4992-078 Transformer
D312 5636-1N4148M Diode T701 5583-52301 Coil AF CH
D315 5636-1N4148M Diode
D501 5632-1N4002E Diode, RL1N4002-E
D552 5635-RD6R8ES2 Zener;6.8V
D553 5636-1N4148M Diode MISCELLANEOUS
D554 5636-1N4148M Diode
D555 5635-RD3R3ES2 Zener;3.3V CF201 5671-02810452 Ceramic Filter;(4.5MHz BAND PASS F.)
D559 5635-RD9R1ES2 Zener;9.1V CF301 5671-02410452 Ceramic Filter;(4.5MHz TRAP)
D601 5685-RS204LST Bridge Silicon Diode CN501 4443-0501142 Connector 5-pin;(DY)
D602 5632-1N4004E Diode, RL1N4004-E CN601 4443-10101002 Connector 2-pin.;(DEGAUSS)
D603 5632-1N4002E Diode, RL1N4002-E CN801 4443-03201003 Connector;(SP)
D605 5635-RD8R2ES2 Zener;8.2V FB551 5597-51001 Ferrite Bead
D606 5632-1N4002E Diode, RL1N4002-E FH601 4472-05001 Fuse Holder;(FU601)
D607 5636-1N4148 Diode FH602 4472-05001 Fuse Holder;(FU601)
D671 5632-1F4-E Diode, 1F4 FU601 5732-02401402 Fuse;(4A/125V)
D672 5632-1F4-E Diode, 1F4 J701 4481-01602 Jack;(VIDEO INPUT)
D673 5632-1F4-E Diode, 1F4 J702 4481-01603 Jack;(AUDIO INPUT)
D681 5632-1F4-E Diode, 1F4 JL101 4242-R0505401 Jumper Lead 5-Wire;(MAIN~CRT)
D701 5632-1F4-E Diode, 1F4 JL102 4242-R0504301 Jumper Lead 4-Wire;(MAIN~CRT)
D702 5636-1N4148M Diode P1 4161-14701212 Cord w/Plug;(AC CORD)
D703 5636-1N4148M Diode RL601 4331-03403 DC Relay
D801 5636-1N4148M Diode RX101 6143-02401 Remote Control Receiver Unit
D802 5636-1N4148M Diode S101 4437-00611 Push Switch
S102 4437-00611 Push Switch
CONTROLS S103 4437-00611 Push Switch
S104 4437-00611 Push Switch
VR701 5101-10301934 10 k ohm Variable Resistor S105 4437-00611 Push Switch
VR702 5101-10301934 10 k ohm Variable Resistor SF201 5679-01501450 Surface Acoustic Wave Filter
TE1 4363-01201 Antenna Coupler;(ANT)
Ref No. Ref No.
- 23 -
