Page #25 background imageLoading...
Page #25 background image
Part No. Description Part No. Description
MISCELLANEOUS
TH601 5192-01801 Posistor
TU1 6119-15502 VHF/UHF/CATV Tuner Assembly
X101 5691-S2401802 Crystal Osc.8.0MHz;(8.0MHz)
X301 5691-S2401362 Crystal Osc. 3.579545MHz;(3.57945MHz)
X551 5693-SB503F30 Ceramic Osc. 503 kHz;(503kHz)
CAPACITORS TRANSISTORS
C451 5361-471KB 470 pF +-10% 50V Ceramic B Q451 5613-1473A(R) Transistor, 2SC1473A(R)
C452 5361-471KB 470 pF +-10% 50V Ceramic B Q452 5613-1473A(R) Transistor, 2SC1473A(R)
C453 5361-471KB 470 pF +-10% 50V Ceramic B Q453 5613-1473A(R) Transistor, 2SC1473A(R)
C454 5361-S11BK102 1000 pF +-10% 2 kV Ceramic
MISCELLANEOUS
RESISTORS
SU451 4474-08001 Socket
R451 5171-S071J153 15 k ohm +-5% 1W Metal
R452 5171-S071J153 15 k ohm +-5% 1W Metal
R453 5171-S071J153 15 k ohm +-5% 1W Metal
R454 5134-272J25P 2.7 k ohm +-5% 1/4W Carbon
R455 5134-272J25P 2.7 k ohm +-5% 1/4W Carbon
R456 5134-272J25P 2.7 k ohm +-5% 1/4W Carbon
R457 5232-331J16P 330 ohm +-5% 1/6W Carbon
R458 5134-152J25P 1.5 k ohm +-5% 1/4W Carbon
R459 5232-331J16P 330 ohm +-5% 1/6W Carbon
R460 5134-152J25P 1.5 k ohm +-5% 1/4W Carbon
R461 5232-331J16P 330 ohm +-5% 1/6W Carbon
R462 5134-152J25P 1.5 k ohm +-5% 1/4W Carbon
R471 V5133-R010J221 220 ohm +-5% 1/8W Carbon
Note:
Safety Related Components.
R472 V5133-R010J221 220 ohm +-5% 1/8W Carbon Use Only Exact Replacement Parts.
R473 V5133-R010J221 220 ohm +-5% 1/8W Carbon
Ref No.
PCB-2 CRT SOCKET P.C.BOARD(D551-13T102B)
Ref No.
- 24 -
