VG0969_B1 2/14/13 1
STANDARD UNIT
UNIT WITH OPTIONAL
HEAT SHIELD KIT VGBHSK
A 18” 18”
B 3/8” 3/8”
C 2” 2”
D 3.5” 3.5”
E 18” 1/8”
F 30” 30”
Clearance To Combustible Materials
WARNING: The structure and surrounding objects MUST maintain the specified minimum clearance to combustible
materials.
Built-in structures constructed of wood or other combustible materials may require the use of the OPTIONAL Built- In Heat Shield
Kit to maintain the required clearance to combustible materials. The grill may be supported by either the three support brackets, or
the four leveling feet. Please note that there must be at least 3/8” clearance between the bottom of the grill and the structure.
Maintain the clearance to combustible materials as specified below.
A MAJOR CAUSE OF FIRES IS FAILURE
TO MAINTAIN REQUIRED CLEARANCES
(AIR SPACES) TO COMBUSTIBLE
MATERIALS. IT IS OF UTMOST
IMPORTANCE THAT THIS PRODUCT BE
INSTALLED ONLY IN ACCORDANCE
WITH THESE INSTRUCTIONS
