Built-In Grill Bill of Materials
TEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY
1 VGE0112
REVERSIBLE
HOPPER LID
1 18 VG0917 4” CURVED RTD 1
2 VGE1101
ELITE HOOD
ASSEMBLY
1 19 VG0956 MEAT PROBE 1
3 VGE0162 FILL SHIELD 1 19 VG0911 120V POWER CORD 1
4 VG0991
1 RPM AUGER
MOTOR (120V)
1 20 VG0911E 230V POWER CORD 1
4 VG0991E
1 RPM AUGER
MOTOR (230V)
1 21 VG0808
CONTROLLER COVER
PLATE
1
5 DS2186
10-24 X 1/2” PH SS
SCREW
4 22 VG0814
CONTROLLER
MOUNTING BRACKET
2
6 VGE0801
REAR SUPPORT
BRACKET
1 22 VG1920 CONTROLLER (120V) 1
7 VGE0115 REAR ACCESS PANEL 1 23 VG1920E CONTROLLER (230V) 1
8 VG0997
COMBUSTION FANS
(120V)
2 24 VG0959B
BUILT-IN WIRE
HARNESS
1
8 VG0997E
COMBUSTION FANS
(230V)
2 25 VG0803
LEFT SUPPORT
BRACKET
1
9 DS2187 SHOULDER BOLT 6 26 VGE4403
FLAVORIZER
ASSEMBLY, WITH
REMOVABLE INSERT
1
10 DS2311
1/4-20 x .625 SS
HEX BOLT
10 27 VG4401 LARGE COOK GRATE 3
11 VGBHSK
(OPTIONAL)
MEMPHIS BUILT-IN
HEAT SHIELD KIT
1 28 VG4406 SMALL COOK GRATE 1
12 VG0802
RIGHT SUPPORT
BRACKET
1 29 VGE0151 ELITE FINGER GUARD 1
13 DS4668 LEVELING FOOT 4 30 VG0104 HANDLE ASSEMBLY 1
14 VGE1805
ASH DRAWER (LEFT,
CENTER, RIGHT)
3 31 DS2185
10-24 X 1/2” PH BLACK
SCREW
4
15 VS0955
IGNITER
CARTRIDGE (120V)
1 32
DS2349
CONCRETE ANCHOR,
5/16" PILOT HOLE
2
15 VS0955E
IGNITER
CARTRIDGE (230V)
1 33
DS2350
#10 SS PH. SCREW,
1¾” LONG
2
17 VG2125
BURN POT
ASSEMBLY
1
