Functional Description
20G233-00 E1
2017-10-20
Page 17
3 Functional Description
3.1 Power Supply
The G233 is supplied via the backplane.
3.2 Web Browser
The web browser running on the G233 supports:
Display of content of the HTML file provided by the web server on the host CPU, no
other sources possible
HTML data input with support of a limited number of HTML tags.
Update rate of 100 ms or better
Character encoding: UTF-8
Fonts in 3 different sizes: normal, bold and italics. Every font has to be saved in nine
versions. The font library is expandable to up to 3000 fonts.
Communication with different web servers. The default web server is hard coded.
The web server can be changed using the href attribute.
Error behavior with configurable timeout values.
See Chapter 3.3 Structure of HTML Files on page 19 for a detailed description.
See Table 2, HTML tags: control tag for timer configuration on page 20 for a
detailed description.
