MEN G233 - Reset Behavior; Memory Details

Functional Description
20G233-00 E1

2017-10-20
Page 22
3.4 Reset Behavior
The G233 supports the RST_IN signal on CompactPCI Serial connector P1.
If the G233 receives a reset signal, the application stops the communication with the
server and the display is turned off.
3.5 Memory
3.5.1 Flash
The G233 supports a Flash memory for storing fonts.
3.5.2 SRAM
The G233 supports an SRAM memory. For better application performance, the font
library is loaded from Flash to SRAM while the system is booting
3.6 User LEDs
Table 4. User LEDs at front panel
Appearance Label Color Function
[1:8] Blue User-defined functionality
1
2
3
4
5
6
7
8
