IMPORTANT
THIS MENVIER FIRE PANEL IS DESIGNED TO BE USED WITH POLARISED AND
SUPPRESSED BELLS. DO NOT USE WITH UNSUPPRESSED BELLS, UNSUPPRESSED
RELAYS OR NON-POLARISED SOUNDERS OR STROBES ETC. DO NOT CONNECT 230V
MAINS DIRECTLY TO THE PCB. ELECTRICAL INSULATION TESTS SHOULD NOT BE
CARRIED OUT WITH THE CABLES CONNECTED TO THE PANEL OR DETECTORS OR
SOUNDERS.
BEFORE MOUNTING THE PANEL PLEASE CARRY OUT THE FOLLOWING TEST:
CONNECT ALL END OF LINE RESISTORS TO ZONE AND ALARM LINE TERMINALS
(SEE FIG. 3 PG. 27). CONNECT A MAINS SUPPLY,THAT IS NOT SWITCHED ON,TO THE
PANEL. SCREW THE CENTRE SECTION INTO PLACE ON THE BACK BOX. CONNECT THE
BATTERIES AND THEN SWITCH ON THE MAINS SUPPLY.
CHECK THAT ALL LIGHTS EXTINGUISH APART FROM THE POWER ON LIGHT. SELECT
LAMP TEST AND CHECK THAT ALL LAMPS LIGHT AND THE INTERNAL BUZZER
SOUNDS. IF ANY FAULT EXISTS THEN PLEASE CONTACT THE MENVIER SALES OFFICE.
ACCESSORIES
MBG913 Flush Mounting Call Point
MBG914 Surface Mounting Call Point
MBG917 Weatherproof Call Points
MMT760 Medium Response Heat Detector
MHT790 High Temp. Response Heat Detector
MFR730 Fast Response Heat Detector
MID710 Ionisation Smoke Detector
MDP720 Photoelectric Smoke Detector
MDB700 Common Detector Base
MBB244 4ins (100mm) Bell
MBM246 6ins (150mm) Bell
MBM248 8ins (200mm) Bell
MWB824 8ins (200mm) Weatherproof Bell
MDS724 Ceiling Sounder
MFS324 Flush Sounder
MWS424/DB Weatherproof Sounder - Deep Base
MWS424/SB Sounder - Shallow Base
MCD524/DB Combined Sounder/Beacon - Deep Base
MCD524/SD Combined Sounder/Beacon - Shallow Base
MXB124/DB Xenon Beacon - Deep Base (1W)
MXB124/SB Xenon Beacon - Shallow Base (1W)
MXB224/DB Xenon Beacon - Deep Base (2W)
MXB224/SB Xenon Beacon - Shallow Base (2W)
MAS175 Discrete Sounder/Indicator
MAR724 Heavy Duty Replay
