Merach MR-S19 - Install the Pedals

Step6:InstallthePedals
A.Assembletheleftandrightpedals(#20L)and(#20R)
withthestrapsasshowninFigure.
B.Locktheleftandrightpedals(#20L)and(#20R)
onthecrank(#29)respectively.
10
AssemblyInstructions
LeftPedal:AligntheLeftPedal(#20L)withtheLeftCrankArmat90degrees.Insertpedalinto
crankarm,thenturnpedalcounter-clockwiseastightlyasyoucanbyhand.Tightenand
securewithOpenSpanner(#D).
RightPedal:AligntheRightPedal(#20R)withtheRightCrankArmat90degrees.Insertpedal
intocrankarm,thenturnpedalclockwiseastightlyasyoucanbyhand.Tightenandsecure
withOpenSpanner(#D).
