NOTE
:
In this step, DO NOT tighten any bolt until you connect all part together
NOTE
:
In this step, DO NOT tighten any bolt until you connect all part together
K 1PC
4*59
STEP 6
: Following below illustration Assembly Frame #6. Using hardware #B, #F, #G connect #13 with
#14 to complete Frame #6.
STEP 7
: Following below illustration Assembly Frame #7. Using hardware #A, #D connect Frame #1,
Frame #2 with Frame #3, Frame #4 to complete Frame #7.
K 1PC
4*59
D 2PCS
1/4*15
A
D
B 4PCS
1/4*40
A 16PCS
1/4*45
F 2PCS
40*20
G 2PCS
25*25
Frame #1
Frame #2
Frame #4
Frame #3
A*16
D
D
PAGE 7 OF 8
TWIN OVER TWIN BUNK BED
ASSEMBLY INSTRUCTIONS
SKU : MF285671
F*2
G*2
B*4
13
14
To Next Page
