Smoke and Heat Exhaust Control Unit mcr 9705 – User Instruction Manual
Strona 22 z 24
9. Technical specifications
The data in the table below applies to the control panel with a single module:
Item
Value
Base type:
5 A
8 A
Control unit type
conventional
Power supply voltage – basic power supply
230 V
%10
%15


50 Hz
Rated power
150 VA
250 VA
Output voltage (power supply for actuators)
24 V DC, max.
5,2 A
24 V DC, max. 8 A
Stand-by power supply
2 pcs. of batteries (3,2 Ah, 12 V)
connected in series
Charging voltage for set of batteries
27,5 V 0,2 V @20C
Working temperature range
-5C ... +55C
Maximum number of sensors in line:
20 pcs.*
Maximum number of RPO-1 pushbuttons:
8 pcs.
Maximum number of actuators – by type:
MCRL KT10x and MCRL KR10x
or
KT10x and KR10x
5 pcs.
8 pcs.
MCRW 08x or G08x or SG08x or S08x
6 pcs.
10 pcs.
MCRW 10x or G10x or SG10x or S10x
5 pcs.
8 pcs.
MCRW 16x or G16x or SG16x
3 pcs.
5 pcs.
MCRW 20x or G20x or SG20x
2 pcs.
4 pcs.
MCRW 26x or G26x or SG26x
2 pcs.
3 pcs.
MCRW 40x or G40x or SG40x
1 pcs.
2 pcs.
MCRW 60x or G60x or SG60x
-
1 pcs.
MCRW 80x or G80x or SG80x
-
1 pcs.
(other types of electric actuators depending
upon consumed and maximum current.)
-
-
Maximum number of electromagnetic door
locks – by type:
mcr TE 50
40 pcs.
40 pcs.
mcr TE 100
30 pcs.
30 pcs.
The maximum number of curtain modules
CE/CE1
2 pcs.
Width < 4 m
2 pcs.
Width >= 4 m
The maximum number of curtain modules
FSv2 CE
12 pcs.
Operation time without mains voltage, in
READY mode
min. 72 h**
Load for relay outputs
max 100 mA, 24 V
Environmental class according to KOT
I
Environmental class of the power supply
according to PN-EN 12101-10
I
Protection level for housing
IP 54
Dimensions (H x W x D)
300 x 300 x 120 mm
* In standby mode, the current consumption of 1 sensor cannot exceed 60 μA!
** After this time, the control unit can open actuators once and alarm for 30 minutes.
The backup time in the door automation mode depends on the number of connected
devices.
