Mercury 15 E - Page 123

WIRING DIAGRAMS
113
a - Main switch
b - Neutral switch
c - Starter motor
d - Starter cord
e - Starter solenoid
f - Fuse
g - Rectifier
h - Tachometer
i - Tachometer lead wire (optional)
j - Separate cord, yellow (optioal)
k - Separate cord, white (optioal)
l - Flywheel magneto
m -Spark plugs
n - Ignition coil
o - CD unit
p - Stop switch
q - 12V 40AH or 12V 70AH (abilable on the market)
