Passenger compartment fuse panel
The fuse panel is located on the left
hand side of the instrument panel
facing the driver’s side door. Pull the
panel cover outward to access the
fuses.
To remove a fuse use the fuse puller tool provided on the fuse panel
cover.
1234
5678
9 101112
13 14 15 16
17 18 19 20
21 22 23 24
25 26
29 30
35
36
31
32
33
34
27 28
Roadside emergencies
172
