Mercury 5 SERIES User Manual

CYLINDER BLOCK AND CRANKCASE
90-857138R1 MAY 2000 Page 4B–17
8. Disassemble the oil pump
c
d
e
f
a
b
a-Bolt (2) M6 x 20 mm
b-Cover
c-O-Ring Seal
d-Rotor - Outer
e-Rotor - Inner
f-Pin
9. Pull out the lower oil seal.
a
a-Lower Oil Seal

Mercury 5 SERIES Specifications

General

Horsepower	5 hp
Cylinders	1
Starting	Manual
Full Throttle RPM Range	5000-6000
Fuel Induction System	Carburetor
Shaft Length	15"
Recommended Fuel	87 octane
