TILLER HANDLE
90-857138R1 MAY 2000 Page 7B-9
Installation
1. Install inner bushing in bottom cowl. Lubricate bushing with 2-4-C w/Teflon Marine Lubri-
cant.
57500
a
95
2-4-C With Teflon (92-825407A12)
95
a-Inner Bushing
2. Insert throttle cables through plate and inner bushing.
57499
a
b
a-Cables
b-Retainer Plate
