Mercury 5 SERIES User Manual

FUEL PUMP & INTREGAL FUEL TANK
90-857138R1 MAY 2000 Page 3A-11
INTEGRAL FUEL TANK (4 HP MODELS ONLY)
REF
REF
.
NO.
QTY. DESCRIPTION
1
1 FUEL TANK
1
1 FUEL TANK (BODENSEE)
2
1 FUEL CAP
2
1 FUEL CAP (BODENSEE)
3 1 GASKET
4 1 SEAL
5 2 SCREW
6 4 WASHER
7 5 RUBBER MOUNT
8 2 SPACER
9 1 BOLT
10 1 SCREW
11 1 CLAMP
12 1 RUBBER MOUNT
13 2 NUT
14 1 BRACKET
15 1 BRACKET
16 1 TUBING (9-7/8 IN.)
17 14 CLIP
18 1 TUBING (14 IN.)
19 1 FUEL COCK
20 2 SCREW
21 1 TUBING (1-3/8 IN.)
22 1 TUBING (8-1/2 IN.)
23 1 TEE FITTING
24 1 TUBING (5-1/4 IN.)
25 2 STA STRAP
26 1 CONNECTOR
27 1 HOSE (1-3/4 IN.)
28 1 FUEL CONNECTOR
29 1 BOLT
30 1 WASHER
31 1 PROTECTOR
32 1 FUEL FILTER
33 1 HOSE (7-1/8 IN.)
34 1 SLEEVE
35 1 BOLT (M6x45) (4 HP)
1 BOLT (M6x40) (5/6 HP)
36 1 BOLT (M6x30) (4 HP)
1 BOLT (M6x25) (5/6 HP)
37 1 PLATE
38 1 SPACER
