Mercury 60 - Features and Controls

Remote Control Features
Your boat may be equipped with one of the Mercury Precision or Quicksilver
remote controls shown. If not, consult your dealer for a description of the
functions and operations of the remote control.
a - Control handle – forward, neutral, reverse
b - Neutral release lever
c -
Trim/tilt switch (if equipped) – Refer to Features and Controls –
Power Trim and Tilt
d -
Lanyard stop switch – Refer to General Information – Lanyard Stop
Switch
e -
Lanyard – Refer to General Information – Lanyard Stop Switch
f - Throttle friction adjustment – Console controls require cover removal for
adjustment
g - Ignition key switch – "OFF," "ON," START"
h -
Fast idle lever – Refer to Operation – Starting the Engine
i -
Throttle only button – Refer to Operation – Starting the Engine
f
a
c
d
e
b
h
c
a
g
d
e
b
i
f
g
i
c
a
f
26800
FEATURES AND CONTROLS
24 eng
