• Tilt support lever ‑ Lubricate through fitting.
a - Tilt support lever
b - Swivel bracket
• Tilt tube ‑ Lubricate through fitting.
29575
• Tiller handle ‑ Lubricate through fitting.
29576
• Clamp screw threads.
3906
a
b
29574
MAINTENANCE
68 eng
