Fuel Hose Size
Minimum fuel hose inside diameter (ID) is 8 mm (5/16 in.) with separate fuel
hose/fuel tank pickup for each engine.
53883
Quick disconnect fuel hose fitting
SHIFT CABLE INSTALLATION
Install cables into the remote control following the instructions provided with the
remote control.
NOTE: Install the shift cable to the engine first. The shift cable is the first cable
to move when the remote control handle is moved out of neutral.
1. Position the remote control and outboard into neutral position.
OUTBOARD INSTALLATION
eng 125

Mercury 80 Specifications

General

Steering	Remote
Shaft Length	20 in (508 mm)
Gear Ratio	2.07:1
Horsepower	80 hp
Full Throttle RPM Range	5000-6000 RPM
Bore x Stroke	3.15 x 3.15 in (80 x 80 mm)
