INSTALLATION
44
• Shift side: Attach the sleeve B guide to the end of the cable
and secure it with the nut.
40469
a
b
c
d
e
f
g
a - Cable outer groove
b - Shift cable
c - Nut
d - Sleeve B guide
e - Lock pin
f - Spring
g - Spring pin
Fitting of remote control cable to the engine
• Throttle side: Set the throttle cable to the cable clip and
connect the holder cap to the ball joint of advancer arm.
